Desktop Processor 6 Cores up to 4.3 GHz

View now

Memory Specifications

• Max Memory Size (dependent on memory type)
• 128 GB
•

• Memory Types
• DDR4-2666
•

• Max # of Memory Channels
• 2
•

• Max Memory Bandwidth
• 41.6 GB/s
•

• ECC Memory Supported ‡
• No
•


Processor Graphics

• Processor Graphics ‡
• Intel® UHD Graphics 630
•

• Graphics Base Frequency
• 350 MHz
•

• Graphics Max Dynamic Frequency
• 1.10 GHz
•

• Graphics Video Max Memory
• 64 GB
•

• 4K Support
• Yes, at 60Hz
•

• Max Resolution (HDMI)‡
• 4096 x 2160@30Hz
•

• Max Resolution (DP)‡
• 4096 x 2304@60Hz
•

• Max Resolution (eDP - Integrated Flat Panel)‡
• 4096 x 2304@60Hz
•

• DirectX* Support
• 12
•

• OpenGL* Support
• 4.5
•

• Intel® Quick Sync Video
• Yes
•

• Intel® InTru™ 3D Technology
• Yes
•

• Intel® Clear Video HD Technology
• Yes
•

• Intel® Clear Video Technology
• Yes
•

• # of Displays Supported ‡
• 3
•

• Device ID
• 0x9BC8 / 0x9BC5
•


Expansion Options

• Scalability
• 1S Only
•

• PCI Express Revision
• 3.0
•

• PCI Express Configurations ‡
• Up to 1x16, 2x8, 1x8+2x4
•

• Max # of PCI Express Lanes
• 16
•


Package Specifications

• Sockets Supported
• FCLGA1200
•

• Max CPU Configuration
• 1
•

• Thermal Solution Specification
• PCG 2015C
•

• TJUNCTION
• 100°C
•

• Package Size
• 37.5mm x 37.5mm
•


Advanced Technologies

• Intel® Optane™ Memory Supported ‡
• Yes
•

• Intel® Thermal Velocity Boost
• No
•

• Intel® Turbo Boost Max Technology 3.0 ‡
• No
•

• Intel® Turbo Boost Technology ‡
• 2.0
•

• Intel vPro® Platform Eligibility ‡
• No
•

• Intel® Hyper-Threading Technology ‡
• Yes
•

• Intel® Virtualization Technology (VT-x) ‡
• Yes
•

• Intel® Virtualization Technology for Directed I/O (VT-d) ‡
• Yes
•

• Intel® VT-x with Extended Page Tables (EPT) ‡
• Yes
•

• Intel® Transactional Synchronization Extensions
• No
•

• Intel® 64 ‡
• Yes
•

• Instruction Set
• 64-bit
•

• Instruction Set Extensions
• Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
•

• Idle States
• Yes
•

• Enhanced Intel SpeedStep® Technology
• Yes
•

• Thermal Monitoring Technologies
• Yes
•

• Intel® Identity Protection Technology ‡
• Yes
•

• Intel® Stable Image Platform Program (SIPP)
• No
•


Security & Reliability

• Intel® AES New Instructions
• Yes
•

• Secure Key
• Yes
•

• Intel® Software Guard Extensions (Intel® SGX)
• Yes with Intel® ME
•

• Intel® OS Guard
• Yes
•

• Intel® Trusted Execution Technology ‡
• No
•

• Execute Disable Bit ‡
• Yes
•

• Intel® Boot Guard
• Yes
